Specifications:
Enclosure: Aluminum die cast
Temperature Range: 0..65 °C
Gears and Bearings: Metal and bronze
External Fasteners Stainless Steel
Weight 800g
Wire Connector PG7 or Prewired Connector
Motor Brushless DC
Voltages 12-24VDC
Current Max 3A
Motion, Position and Feedback:
Control and Feedback Analog: 4..20mA, 1-5V, 1 – 10V
Control and Feedback Digital: Modbus RTU, Modbus TCP Can BUS (CANopen, J1973) BLE v4.0
Position resolution: +/- 0.15 degree
Position precision: +/- 0.3 degree
Power Setting: 12..48 in-lbs
Speed Setting 10 to 60 RPM
End travel detection: Motion and Current Detection
